Weight & size

GUIDES

Weight & size

Weight & dimensions of each detail, sorted in table by article number. You can also see all dimensions and weights on the articles in the webshop.

Weight & size chart

Art.no. Description Weight (g) Dimension L/W/H (mm)
100230 OPEN SPIRIT STOVE 285 Ø152x82
100281 WIND+B25 162 Ø95x62
100285 MINI TRANGIA 350 Ø150x67
120251 TRANGIA STOVE 1130 Ø220x105
120253 TRANGIA STOVE 1090 Ø220x105
120271 TRANGIA STOVE 885 Ø185x100
120273 TRANGIA STOVE 855 Ø185x100
127251 TRANGIA STOVE 1251 Ø220x105
127253 TRANGIA STOVE 1175 Ø220x105
127271 TRANGIA STOVE 970 Ø185x100
130255 TRANGIA STOVE 930 Ø220x105
130275 TRANGIA STOVE 770 Ø185x100
140251 TRANGIA STOVE 845 Ø220x105
140251 TRANGIA STOVE 845 Ø220x105
140252 TRANGIA STOVE 1025 Ø220x105
140253 TRANGIA STOVE 895 Ø220x105
140254 TRANGIA STOVE 1075 Ø220x105
140255 TRANGIA STOVE 905 Ø220x105
140256 TRANGIA STOVE 1085 Ø220x105
140271 TRANGIA STOVE 690 Ø185x100
140272 TRANGIA STOVE 825 Ø185x100
140273 TRANGIA STOVE 725 Ø185x100
140274 TRANGIA STOVE 860 Ø185x100
140275 TRANGIA STOVE 745 Ø185x100
140276 TRANGIA STOVE 880 Ø185x100
140355 TRANGIA STOVE 1075 Ø220x105
140375 TRANGIA STOVE 880 Ø185x100
140625 TRANGIA STOVE /LEATHER 1099 Ø220x120
140627 TRANGIA STOVE /LEATHER 899 Ø190x120
147251 TRANGIA STOVE 930 Ø220x105
147252 TRANGIA STOVE 1110 Ø220x105
147253 TRANGIA STOVE 980 Ø220x105
147254 TRANGIA STOVE 1160 Ø220x105
147255 TRANGIA STOVE 990 Ø220x105
147256 TRANGIA STOVE 1170 Ø220x105
147271 TRANGIA STOVE 775 Ø185x100
147273 TRANGIA STOVE 810 Ø185x100
147275 TRANGIA STOVE 830 Ø185x100
150251 TRANGIA STOVE 845 Ø220x105
150252 TRANGIA STOVE 1025 Ø220x105
Art.no. Description Weight (g) Dimension L/W/H (mm)
150253 TRANGIA STOVE 895 Ø220x105
150254 TRANGIA STOVE 1075 Ø220x105
150255 TRANGIA STOVE 905 Ø220x105
150256 TRANGIA STOVE 1085 Ø220x105
150271 TRANGIA STOVE 690 Ø185x100
150272 TRANGIA STOVE 825 Ø185x100
150273 TRANGIA STOVE 725 Ø185x100
150274 TRANGIA STOVE 860 Ø185x100
150275 TRANGIA STOVE 745 Ø185x100
150276 TRANGIA STOVE 880 Ø185x100
157251 TRANGIA STOVE 930 Ø220x105
157252 TRANGIA STOVE 1110 Ø220x105
157253 TRANGIA STOVE 980 Ø220x105
157254 TRANGIA STOVE 1160 Ø220x105
157255 TRANGIA STOVE 990 Ø220x105
157256 TRANGIA STOVE 1170 Ø220x105
157271 TRANGIA STOVE 775 Ø185x100
157273 TRANGIA STOVE 810 Ø185x100
157275 TRANGIA STOVE 830 Ø185x100
160250 TRANGIA STOVE 1075 Ø220x105
160257 TRANGIA STOVE 845 Ø220x105
160258 TRANGIA STOVE 1025 Ø220x105
160259 TRANGIA STOVE 895 Ø220x105
160270 TRANGIA STOVE 860 Ø185x100
160277 TRANGIA STOVE 690 Ø185x100
160278 TRANGIA STOVE 825 Ø185x100
160279 TRANGIA STOVE 725 Ø185x100
162423 CAMPING SET 600 Ø185x100
167250 TRANGIA STOVE 1160 Ø220x105
167257 TRANGIA STOVE 930 Ø220x105
167258 TRANGIA STOVE 1110 Ø220x105
167259 TRANGIA STOVE 980 Ø220x105
167277 TRANGIA STOVE 775 Ø185x100
167279 TRANGIA STOVE 810 Ø185x100
200245 KETTLE 1.4L 201 Ø152x106
200324 KETTLE 0.9L 175 Ø152x85
200325 KETTLE 0.6L 127 Ø132x70
200824 KETTLE 0.9L 189 Ø139x95
200825 KETTLE 0.9L 195 Ø139x95
200924 KETTLE 0.9L Stainless knob 195 Ø139x95
Art.no. Description Weight (g) Dimension L/W/H (mm)
203240 LID 28 Ø108x20
203241 LARGE W STAINLESS KNOB 28 Ø108x20
203250 LID 24 Ø99x19
203251 SMALL W STAINLESS KNOB 24 Ø99x19
203324 KETTLE 0.9L Stainless knob 175 Ø152x85
203325 KETTLE 0.6L stainless knob 127 Ø134x70
307240 FRYPAN 244 Ø195x28
307241 FRYPAN no handle 160 Ø195x28
307242 FRYPAN 285 Ø220x37
307250 FRYPAN 228 Ø195x28
307251 FRYPAN no handle 167 Ø195x28
307252 FRYPAN 263 Ø220x37
307254 FRYPAN 390 Ø240x40
307258 XL FRYPAN 340 Ø290x55
307260 FRYPAN 359 Ø200x82
400124 CAMPING SET 612 Ø205x95
400240 CAMPING SET 915 Ø200x135
400246 CAMPING SET 1120 Ø200x135
400333 TRIANGLE 115 Ø126x85
400524 COOKING POT 240 Ø170x82
401124 CAMPING SET 612 Ø205x95
401251 CAMPING SET 489 Ø200x95
401252 CAMPING SET 399 Ø200x95
401253 CAMPING SET 566 Ø200x95
402252 CAMPING SET 571 Ø200x95
402253 CAMPING SET 738 Ø200x95
403252 CAMPING SET 440 Ø200x95
403253 CAMPING SET 620 Ø200x95
404273 TUNDRA III MINI 365 Ø150x80
406241 CAMPING SET 315 Ø185x80
406280 CAMPING SET 510 Ø185x100
406287 CAMPING SET 535 Ø185x100
500020 PLATE 90 Ø200x28
500021 WINTER ATTACHEMENT 225 Ø200
500209 MESS TIN 257 200x130x70
500210 MESS TIN 155 165x90x65
500211 MESS TIN 231 200x130x70
500212 MESS TIN 128 165x90x65
500252 MUG/252 50 Ø103x50
500309 MESS TIN RED HANDLE 257 200x130x70
Art.no. Description Weight (g) Dimension L/W/H (mm)
500310 MESS TIN RED HANDLE 155 165x90x65
501252 BILLY POT 320 Ø200x132
501254 BILLY POT 506 Ø238x137
502252 BILLY POT NONSTICK 376 Ø200x132
502254 BILLY POT NONSTICK 500 Ø238x137
503253 BILLY POT NONSTICK 376 Ø200x132
504254 BILLY POT NONSTICK w high lid 567 Ø238x155
506000 SAFETY VALVE 25 64mm
506003 FUELBOTTLE RED 93 Ø65x188
506005 FUELBOTTLE RED 114 Ø65x235
506010 FUELBOTTLE RED 163 Ø80x294
506100 SAFETY VALVE BLACK 25 64mm
506103 FUELBOTTLE OLIVE 93 Ø65x188
506105 FUELBOTTLE OLIVE 114 Ø65x235
506110 FUELBOTTLE OLIVE 163 Ø80x294
530020 PLATE 20CM NS RED 100 Ø200x28
540020 PLATE 20CM NS BLACK 100 Ø200x28
541252 MUG BLACK 58 Ø103X50
550010 T-SPOON 14 161mm
600124 PLATE 20CM 106 Ø200x30
600231 HOLDER OPEN SPIRIT STOVE 175 Ø152x82
600281 WINDSHEILD 51 Ø95x62
600282 HANDLE 20 115mm
600283 POT 90 Ø141x62
600286 FRYPAN 75 Ø150x24
600289 MINI SET JP 185 Ø150x67
601252 LID GOURMET SMALL 99 Ø192x52
601524 LID 64 Ø167x13
602101 PREHEATER 23 Ø70x28
602400 GELBURNER 18 Ø80x26
602401 GELBURNER CUP 10 Ø75x25
602402 GELBURNER LID 8 Ø80x11
602500 SPIRIT BURNER 110 Ø75x42
602505 LID BURNER 22 Ø58x15
602506 SIMMER RING 23 Ø65x18
602507 COVER 26 340x320mm
602508 ORING 4 Ø47,5
602509 MULTIDISC 100 Ø210x0,7
602510 HANDLE 48 128x36
602516 SAUCE PAN 206 Ø168x75
Art.no. Description Weight (g) Dimension L/W/H (mm)
602517 SAUCE PAN 220 Ø179x77
602521 FRYPAN 206 Ø220x31
602707 COVER 24 290x280mm
602709 MULTIDISC 78 Ø180x0,7
602716 SAUCE PAN 150 Ø147x66
602717 SAUCE PAN 150 Ø144x69
602721 FRYPAN 152 Ø184x29
602807 COVER MINI 20 220x220mm
602907 COVER CAMPING SET 30 385x415mm
606100 STRAP 20 610mm
606282 POT (IN SET 406280,287) 167 Ø176x100
606800 STRAP 20 680mm
606811 STRAP 68CM LEATHER 20 680mm
607200 STRAP 21 720mm
607254 HANDLE/725-24 FRYPAN 72 160mm
608240 HANDLE 46 121mm
608500 STRAP 85 CM 22 850mm
610209 HANDLE MESS TIN 209 BLACK 14 119mm
610210 HANDLE MESS TIN 210 BLACK 14 119mm
610309 HANDLE MESS TIN 309 RED 14 119mm
610310 HANDLE MESS TIN 310 RED 14 119mm
610324 HANDLE COVER 200324/325 3 111mm
612410 SAUCE PAN 188 Ø168x73
612420 FRYPAN w handle 298 Ø197x49
612425 FRYPAN nonstick w handle 273 Ø197x49
612527 PAN STAND 48 Ø135
619025 EVA CASE 25 245 Ø235x134
619027 EVA CASE 27 200 Ø205x135
619100 ROLL TOP BAG MESS TIN SMALL, BLACK X Ø
619101 ROLL TOP BAG MESS TIN SMALL, OLIVE X Ø
619102 ROLL TOP BAG MESS TIN LARGE ,BLACK X Ø
619103 ROLL TOP BAG MESS TIN LARGE ,OLIVE X Ø
619200 CASE EVA MESS TIN SMALL 120 190x115x80
619201 CASE EVA MESS TIN LARGE 200 225x155x86
619251 ROLL TOP BAG STOVE 25, BLACK x x
619252 ROLL TOP BAG STOVE 25, OLIVE x x
619300 INSERT COVER ,SMALL MESS TIN x x
619301 INSERT COVER ,LARGE MESS TIN x x
620025 LEATHER CASE 25 254 Ø220x120
620027 LEATHER CASE 27 200 Ø190x120
Art.no. Description Weight (g) Dimension L/W/H (mm)
620210 Messtin handle Tan 12 120x44mm
620252 Mug handle Tan 5 48x48mm
621210 Messtin handle Black 12 120x44mm
621252 Mug handle Black 5 48x48mm
632501 FRYPAN RED 161 Ø220x33
632514 SAUCE PAN RED 124 Ø170x75
632515 SAUCE PAN RED 130 Ø181x77
632701 FRYPAN RED 119 Ø188x30
632714 SAUCE PAN RED 84 Ø150x67
632715 SAUCE PAN RED 88 Ø146x69
641253 LID TUNDRA 77 Ø187x15
641254 LID BLACK 120 Ø245x20
641273 TUNDRA LID MINI 50 Ø152x16
642501 FRYPAN 161 Ø220x33
642503 WINDSHEILD 202 Ø200x96
642504 WINDSHEILD 120 Ø207x74
642511 FRYPAN 114 Ø220x33
642512 SAUCE PAN 112 Ø170x75
642513 SAUCE PAN 116 Ø181x77
642514 SAUCE PAN 124 Ø170x75
642515 SAUCE PAN 130 Ø181x77
642701 FRYPAN 119 Ø188x30
642703 WINDSHEILD 167 Ø168x93
642704 WINDSHEILD 93 Ø180x72
642711 FRYPAN 83 Ø188x30
642712 SAUCE PAN 81 Ø150x67
642713 SAUCE PAN 79 Ø146x69
642714 SAUCE PAN 84 Ø150x67
642715 SAUCE PAN 88 Ø146x69
643503 WINDSHIELD UPPER/WU35 BLACK 248 Ø200x96
643504 WINDSHIELD LOWER/WL35 BLACK 169 Ø207x74
643703 WINDSHIELD UPPER/WU37 BLACK 204 Ø168x93
643704 WINDSHIELD LOWER/WL37 BLACK 105 Ø180x72
652503 WINDSHEILD 202 Ø200x96
652504 WINDSHEILD 120 Ø207x74
652511 FRYPAN 112 Ø220x33
652512 SAUCE PAN 112 Ø170x75
652513 SAUCE PAN 116 Ø181x77
652703 WINDSHEILD 167 Ø168x93
652704 WINDSHEILD 93 Ø180x72
Art.no. Description Weight (g) Dimension L/W/H (mm)
652711 FRYPAN 83 Ø188x30
652712 SAUCE PAN 81 Ø150x67
652713 SAUCE PAN 79 Ø146x69
662418 FRYPAN AL (IN SET 406280) 151 Ø180x25
662818 FRYPAN T (IN SET 406287) 160 Ø180x25
742527 GAS BURNER 180 n/a
746007 COVER FOR GB74 25 180x140mm
748006 O-RING FOR GB74 1 Ø11
750001 MULTIFUEL BURNER 525 n/a
750100 SPARE PART SET 20 n/a
750628 JET 0,28MM 2 n/a
750632 JET 0,32MM 2 n/a
751506 AL BOTTLE W LID 110 Ø74x200
751780 PRIMING PAD ,2-pcs 1 Ø38
751860 SERVICE TOOL 42 n/a
751870 FLAME SPREADER 10 n/a
756007 COVER F75 30 250x180x70mm
788205 BURNER CUP 40 Ø83x35
991254 High lid Gourmet 4,5l 172 Ø230x50
999000 YELLOW BAG 2-pcs 10 n/a
